LONGZE Continuous Carbonization Curnace

›

‹

  • LONGZE Continuous Carbonization Curnace

›

LONGZE Continuous Carbonization Curnace
The Environmental Protection Type Rotary Carbonization Furnace is a ideal equipment to destructively distill, anaerobic carbonization the sawdust, rice husk,peanut shell,straw,tree bark etc carbonaceous biomass materials (diameter <15mm) in high temperature.
MESSAGE
CONTACT US
PRODUCT DESCRIPTION
MACHINE LOADING
CUSTOMER CASE
FACTORY CIRNER

1MX12M TECHNICAL PARAMETERS:

LONGZE Continuous Carbonization Curnace

1.2MX12M TECHNICAL PARAMETERS:

Drum diameter

1200mm

Drum  length

11500mm

Feed Power(KW)

3+1.1

Drive motor(KW)

7.5

Fan motor(KW)

11

Oxygen intake fan

80w

The final charcoal output

800-1000kg/h

The heating fuel

Firewood,natural gas, natural gas ,LPG gas,Biomass burner

Cylinder material

304SS or Boiler steel

The feed temperature

350-450°C

Output temperature

50°C

The raw material size

<3cm

The raw material moisture

<15%

The screw loading conveyor

The diameter:325mm,Length:6m, power:3kw

The screw cooling discharge conveyor

Double pipe(outer diameter 325mm,inner diameter 219mm)

Length:6m, power:3kw

Gas purification system

Φ600mm*2000mm, 2pcs

Including one set Electric control cabinet

Wood tar and wood vinegar collector are included

Working continuously

24H
